Naming and Logic (Scheme)
programming essentials with Scheme
This article teaches the core of programming with Guile Scheme. The tutorial starts from scratch and teaches in examples with minimal explanation. It’s core is a map of the minimal functionality you need from Scheme to write meaningful programs. It is translated from the article teaching Programming with Wisp.
I hope that one day this will be interactive, using Guile on wasm (which is currently being built by the folks at Spritely).
To follow along, install Guile and try the examples as you read.
The Map of Scheme
(How to make such a map? See Org Mode Tipp: imagemap)
Preface
Why this book? Providing a concise start, a no-frills, opinionated
intro to programming from first define to deploying an application
on just 64 short pages.
Who is it for? You are a newcomer and want to learn by trying code examples? You know programming and want a running start into Scheme? You want to see how little suffices with Scheme’s Then this book is for you.
What is Scheme? Scheme is a programming language — a Lisp — that follows principle “design not by piling feature on top of feature, but by removing the weaknesses and restrictions that make additional features appear necessary”. This book uses Guile Scheme, the official extension language of the GNU project.
How to get Guile? Download and install Guile from the website
www.gnu.org/software/guile — then open the REPL by executing
guile in the terminal. The REPL is where you type and try code
interactively.
Name a value: define
Use (define ...) to name a value. Return the last name.
(define small-tree-height-meters 3) (define large-tree-height-meters 5) small-tree-height-meters
After typing or copying a block into the Guile REPL, hit enter. You should then see
$1 = 3
This means: the first returned value ($1) is 3. The next time you
return a value, it will be called $2.
Names can contain any letter except for (white-)space, quote, comma or parentheses. They must not be numbers.
(define illegal name 1) (define 'illegal-name 2) (define ,illegal-name 3) (define illegal)name 4) (define 1113841 5)
While executing meta-command: Syntax error: unknown location: source expression failed to match any pattern in form (define illegal name 1) While reading expression: #<unknown port>:14:2: unexpected ")"
Compare numbers
(= 3 3)
#t
(= 3 5)
#f
#t means true, #f means false. Parentheses return the result of logic.
The logic comes first. This is clear for =, but easy to misread for <.
(< 3 5) ;; is 3 smaller than 5? #true
#t
(> 5 3) ;; is 5 bigger than 3? #true
#t
(> 3 3) ;; is 3 bigger than 3? #false
#f
(>= 3 3) ;; is 3 bigger or equal to 3? #true
#t
(<= 3 3) ;; is 3 bigger or equal to 3? #true
#t
Use infix in logic
#!curly-infix
{3 = 5}
#f
#!curly-infix
{3 < 5}
#t
Infix logic directly gives a value. To use it, you must put
#!curly-infix somewhere in your code before you use the first curly
brace ({...}).
Because infix-logic gives a value, you can use it in place of a value, for example to nest or name it:
#!curly-infix
{{5 < 3} equal? #f}
#t
#!curly-infix (define is-math-sane? {3 < 5}) is-math-sane?
#t
By convention, names that have the value true or false have the suffix ?.
Use named values in logic
#!curly-infix (define small-tree-height/m 3) (define large-tree-height/m 5) {small-tree-height/m < large-tree-height/m}
#t
Add comments with ;
(define birch-height/m 3) ;; this is a comment (define height ;; comment at the end ;; comment between lines birch-height/m) height
3
It is common to use ;; instead of ;, but not required.
Logic with true and false
(and #t #t)
#t
(and #f #t)
#f
(or #f #t)
#t
(or #f #f)
#f
If any value passed to and is #f (#false), it ignores further values.
If any value passed to or is not #f (not #false), it ignores further values.
#!curly-infix (and #t #t #t) ;; => #true (and #t #f #t) ;; => #false (and {3 < 5} {5 < 3}) ;; => #false (or #t #f #t) ;; => true (or {3 < 5} {5 < 3}) ;; => #true (or #f #f #f) ;; => #false
For and and or, everything is #true (#t) except for #false (#f).
Given the number of hard to trace errors in other languages that turn
up in production, this is the only sane policy.
Name the result of logic with indentation
#!curly-infix (define birch-h/m 3) (define chestnut-h/m 5) (define same-héight? (= birch-h/m chestnut-h/m)) (define smaller? {birch-h/m < chestnut-h/m}) ;; infix smaller?
#t
The infix gives a value, so it directly returns its value.
Name logic with define (
(define (same-height? tree-height-a tree-height-b) (= tree-height-a tree-height-b)) (same-height? 3 3)
#t
By convention, logic that returns true or false has the suffix ?.
You can now use your named logic like all other logic. Even with infix.
#!curly-infix (define (same-height? tree-height-a tree-height-b) (= tree-height-a tree-height-b)) {3 same-height? 3}
#t
What this map of Scheme calls named logic is commonly called
function or procedure. We’ll stick with logic for the sake of
a leaner conceptual mapping.
The indented lines with the logic named here are called the body.
Name a name with define
(define small-tree-height-meters 3) (define height small-tree-height-meters) height
3
Return the value of logic
#!curly-infix (define (larger-than-4? size) {size > 4}) larger-than-4?
#<procedure larger-than-4? (size)>
The value of logic defined with define ( is a procedure. You can
see the arguments in the output: If you call it with too few or too
many arguments, you get warnings.
There are other kinds of logic: syntax rules and reader-macros. We
will cover syntax rules later. New reader macros are rarely needed;
using {...} for infix math is a reader macro activated with
#!curly-infix.
Name in define ( with define
#!curly-infix (define birch-h/m 3) (define (birch-is-small) (define reference-h/m 4) {birch-h/m < reference-h/m}) (birch-is-small)
#t
Only the last part of the body of define ( is returned.
A calculation inside curly braces is executed in-place, so when it is the last element, its result value is returned.
A Zen for Scheme part 1: Birds Eye
- RR
- Remove limitations to Reduce the feature-count you need,
but OM: Optimizability Matters. - FI
- Freedom for the Implementations and from Implementations,
but CM: Community Matters: Join the one you choose. - SL
- Mind the Small systems!
And the Large systems! - ES
- Errors should never pass silently,
unless speed is set higher than safety.
Thanks for the error-handling principle goes to John Cowan.
Return list of values with list
(define known-heights (list 3 3.75 5 100)) (list (list 3 5) known-heights)
((3 5) (3 3.75 5 100))
You can put values on their own lines. Different from define (, list
keeps all values, not just the last.
(define known-heights-2 (list 3 3.75 5 100)) ;; ist keeps all numbers (define known-heights-3 (list 3 3.75 5 100)) (define (last-height) 3 3.75 5 100) ;; (define () ...) only keeps 100 (= 100 (last-height))
#t
Name the result of logic in one line with ()
(define birch-h/m 3) (define chestnut-h/m 5) (define same-height (= birch-h/m chestnut-h/m)) same-height
#f
This is consistent with infix-math and uniform with defining logic:
#!curly-infix (define birch-h/m 3) (define chestnut-h/m 5) (define same-height {birch-h/m = chestnut-h/m}) (define (same-height? tree-height-a tree-height-b) (= tree-height-a tree-height-b)) (define same-height2 (same-height? birch-h/m chestnut-h/m)) (list same-height same-height2)
'(#f #f)
Name text with "
(define tree-description "large tree") (define footer "In Love, Arne") (define greeting "Hello") (display footer)
In Love, Arne
Like { }, text (called string as in “string of characters”) is its
value.
Text can span multiple lines. Line breaks in text do not affect the meaning of code.
You can use \n to add a line break within text without having a
visual line break. The backslash (\) is the escape character and
\n represents a line break. To type a real \ within quotes ( "
), you must escape it as \\.
With display you can show text as it will look in an editor.
Text is stronger than comments:
(define with-comment ;; belongs to coment ;; comment "Hello ;; part of the text") with-comment
Hello ;; part of the text
Take decisions with cond
#!curly-infix (define chestnut-h/m 5) (define tree-description (cond ({chestnut-h/m > 4} "large tree") ((= 4 chestnut-h/m) "four meter tree") (else "small tree"))) tree-description
large tree
cond checks its clauses one by one and uses the first with value
#true.
To cond every valid value is #true (#t) except for #false
(#f).
To use named logic, prefix it with : to check its value.
#!curly-infix (list (cond (5 #t) (else ;; else is #true in cond #f)) (cond (#f #f) (else #t)) (cond ({3 < 5} #t) (else #f)))
'(#t #t #t)
Use fine-grained numbers with number-literals
(define more-precise-height 5.32517) (define 100-meters 1e2) (list more-precise-height 100-meters)
(5.32517 100.0)
These are floating point numbers. They store approximate values in 64 bit binary, depending on the platform. Read all the details in the Guile Reference manual Real and Rational Numbers, the r5rs numbers, and IEEE 754.
Use exact numbers with #e and quotients
(define exactly-1/5 #e0.2) (define exactly-1/5-too 1/5) (list exactly-1/5 exactly-1/5-too)
(1/5 1/5)
Guile computations with exact numbers stay reasonably fast even for unreasonably large or small numbers.
See inexact value of exact number with exact->inexact
(list (exact->inexact #e0.2)
(exact->inexact 1/5)
(exact->inexact 2e7))
(0.2 0.2 2.0e7)
The inverse is inexact->exact:
(inexact->exact 0.5)
1/2
Note that a regular 0.2 need not be exactly 1/5, because floating
point numbers do not have exact representation for that. You’ll need
#e to have precise 0.2.
(list (inexact->exact 0.2)
#e0.2)
(3602879701896397/18014398509481984 1/5)
Use math with the usual operators as logic
(define one-hundred (* 10 10)) (define half-hundred (/ one-hundred 2)) half-hundred
50
Remember that names cannot be valid numbers!
(define 100 ;; error! (* 10 10))
ice-9/boot-9.scm:1685:16: In procedure raise-exception:
Syntax error:
unknown location: source expression failed to match any pattern in form (define 100 (* 10 10))
Entering a new prompt. Type `,bt' for a backtrace or `,q' to continue.
Compare structural values with equal?
;; reuse name definition snippets from ;; Return list of values with =list= {{{known-heights}}} {{{known-heights2}}} (equal? known-heights known-heights-2 known-heights-3)
#t
Like = and +, equal? can be used on arbitrary numbers of values.
Reusing the snippets from Return list of values with list uses
noweb syntax via Emacs Org Mode, the .
A Zen for Scheme part 2: On the Ground
- HA
- Hygiene reduces Anxiety,
except where it blocks your path. - PP
- Practicality beats Purity,
except where it leads into a dead end. - 3P
- 3 Pillars of improvement:
Experimentation, Implementation, Standardization.
Apply logic to a list of values with apply
(apply = (list 3 3))
#t
(equal?
(= 3 3)
(apply =
(list 3 3)))
#t
Only the last argument of apply is treated as list, so you can give initial arguments:
(define a 1) (define b 1) (apply = a b (list 1 1)) ;; becomes (= a b 1 1)
#t
Get the arguments of named logic as list with . args
(define (same? heights) (apply = heights)) (define (same2? . heights) (apply = heights)) (list (same? (list 1 1 1)) (same2? 1 1 1))
'(#t #t)
These are called rest. Getting them is not for efficiency: the list creation is implicit.
You can mix regular arguments and rest arguments:
(define (same? alice bob . rest) (display (list alice bob rest)) (newline) (apply = alice bob rest)) (display (same? 1 1 1 1))
(1 1 (1 1)) #t
Remember that apply uses only the last of its arguments as list, in symmetry with . rest.
Change the value or logic of a defined name with set!
(define birch-h/m 3) (set! birch-h/m 3.74) birch-h/m
3.74
It is customary to suffix named logic that changes values of existing names with !.
Since logic can cause changes to names and not just return a result,
it is not called function, but procedure in documentation; proc
for brevity.
Apply logic to each value in lists and ignoring the results with for-each
#!curly-infix (define birch-h/m 3) (define has-birch-height #f) (define (set-true-if-birch-height! height/m) (cond ({birch-h/m = height/m} (set! has-birch-height #t)))) (define heights (list 3 3.75 5 100)) (for-each set-true-if-birch-height! heights) has-birch-height
#t
Get the result of applying logic to each value in lists with map
(define birch-h/m 3) (define (same-height-as-birch? height/m) (= birch-h/m height/m)) (define heights (list 3 3.75 5 100)) (list heights (map same-height-as-birch? heights) (map + ;; becomes 1+3 2+2 3+1 (list 1 2 3) (list 3 2 1)) (map list (list 1 2 3) (list 3 2 1)))
'((3 3.75 5 100) (#t #f #f #f) (4 4 4) ((1 3) (2 2) (3 1)))
When operating on multiple lists, map takes one argument from each
list. All lists must be the same length. To remember: apply
extracts the values from its last argument, map extracts one value
from each argument after the first. apply map list ... flips
colums and rows:
(apply map list
(list (list 1 2 3)
(list 3 2 1)))
((1 3) (2 2) (3 1))
Create nameless logic with lambda
(define (is-same-height? a b) (> a b)) ;; <- this is a mistake (display is-same-height?)(newline) (display (is-same-height? 3 3))(newline) (define (fixed a b) (= a b)) (set! is-same-height? fixed) (display is-same-height?) ;; now called "fixed" (newline) (display (is-same-height? 3 3))(newline) ;; shorter and avoiding name pollution and confusion. (set! is-same-height? (lambda (a b) (= a b))) ;; must be on a new line ;; to not be part of the arguments. ;; since lambda has no name, we see the original name (display is-same-height?) (display (is-same-height? 3 3))
#<procedure is-same-height? (a b)> #f #<procedure fixed (a b)> #t #<procedure is-same-height? (a b)>#t
The return value of lambda is logic (a procedure).
If logic is defined via define (, it knows the name it has been
defined as. With lambda, it does not know the name.
lambda is a special form. Think of it as
(define (name arguments) ...), but without the name.
Reuse your logic with let-recursion
Remember the for-each example:
#!curly-infix (define has-birch-height #f) (define heights (list 3 3.75 5 100)) (define (set-true-if-birch-height! height/m) (define birch-h/m 3) (cond ({birch-h/m = height/m} (set! has-birch-height #t)))) (for-each set-true-if-birch-height! heights) has-birch-height
#t
Instead of for-each, we can build our own iteration:
(define heights (list 3 3.75 5 100)) (define (has-birch-height? heights) (define birch-h/m 3) (let loop ((heights heights)) (cond ((null? heights) #f) ((= birch-h/m (car heights)) ;; car is first #t) (else (loop (cdr heights)))))) (has-birch-height? heights)
#t
null? asks whether the list is empty. car gets the first element
of a list, cdr gets the list without its first element.
Recursion is usually easier to debug (all variable elements are available at the top of the let recursion) and often creates cleaner APIs than iteration.
As rule of thumb: start with the recursion end condition (here:
(null? heights) and ensure that each branch of the cond either
ends recursion or moves a step towards finishing (usually with cdr).
Another example why recursion wins:
(define (fib n) (let rek ((i 0) (u 1) (v 1)) (if (>= i (- n 2)) v (rek (+ i 1) v (+ u v)))))
A Zen for Scheme part 3: Submerged in Code
- WM
- Use the Weakest Method that gets the job done,
but know the stronger methods to employ them as needed. - RW
- Recursion Wins,
except where a loop-macro is better. - RM
- Readability matters,
and nesting works.
Import pre-defined named logic and values with import
(import (ice-9 pretty-print) (srfi :1 lists)) (pretty-print (list 12 (list 34) 5 6)) (pretty-print (list (first (list 1 2 3)) ;; 1 (second (list 1 2 3)) ;; 2 (third (list 1 2 3)) ;; 3 (member 2 (list 1 2 3)))) ;; list 2 3 => #true
(12 (34) 5 6) (1 2 3 (2 3))
Import uses modules which can have multiple components. In the first
import, ice-9 is one component and the second is pretty-print. In
the second, srfi is the first component, :1 is the second, and
lists is the third.
ice-9 is the name for the core extensions of Guile. It’s a play on ice-9, a fictional perfect seed crystal.
SRFI’s are Scheme Requests For Implementation, portable libraries
built in collaboration between different Scheme implementations. The
ones available in Guile can be found in the Guile Reference manual.
More can be found on srfi.schemers.org. They are imported by number
(:1) and can have a third component with a name, but that’s not
required.
You can use only to import only specific names.
(import (only (srfi :1) first second) ;; no third (only (srfi :1) iota)) (first (list 1 2 3)) ;; 1 (second (list 1 2 3)) ;; 2 (third (list 1 2 3)) ;; error (iota 5) ;; list 0 1 2 3 4
ice-9/boot-9.scm:1685:16: In procedure raise-exception:
Unbound variable: third
Entering a new prompt. Type `,bt' for a backtrace or `,q' to continue.
Extend a list with cons
The core of composing elementwise operations.
To build your own map function which returns a list of results, you
need to add to a list.
(cons 1 (list 2 3)) ;; => list 1 2 3
| 1 | 2 | 3 |
Used for a simplified map implementation taking a single list:
(import (only (srfi :1) first)) (define (single-map proc elements) (let loop ((changed (list)) (elements elements)) (cond ((null? elements) (reverse changed)) (else (loop ;; add processed first element to changed (cons (proc (first elements)) changed) ;; drop first element from elements (cdr elements)))))) (single-map even? (list 1 2 3)) ;; => #f #t #f
'(#f #t #f)
Apply partial procedures with srfi :26 cut
(import (srfi :26 cut)) (define (plus-3 number) (+ 3 number)) (define plus-3-cut (cut + 3 <>)) (list (map plus-3 (list 1 2 3)) ;; list 4 5 6 (map (cut + 3 <>) (list 1 2 3)) ;; list 4 5 6 (map (cut - <> 1) ;; => <> - 1 (list 1 2 3)) ;; list 0 1 2 (map (cut - 1 <>) ;; => 1 - <> (list 1 2 3)) ;; list 0 -1 -2 (map plus-3-cut (list 1 2 3))) ;; list 4 5 6
((4 5 6) (4 5 6) (0 1 2) (0 -1 -2) (4 5 6))
Use r7rs datatypes, e.g. with vector-map
R7RS is the 7th Revised Report
on Scheme. Guile provides a superset of the standard: its core can be
imported as scheme base. A foundational datatype is Vectors with
O(1) random access guarantee.
(import (scheme base)) (define vec (list->vector '(1 b "third"))) (vector-map (λ (element) (cons 'el element)) vec)
Vectors have the literal form #(a b c). It is an error to mutate these.
(import (scheme base)) (define mutable-vector (list->vector '(1 b "third"))) (define literal-vector #(1 b "third")) (vector-set! mutable-vector 1 "bee") ;; allowed (vector-set! literal-vector 1 "bee") ;; forbidden (list mutable-vector literal-vector)
Name structured values with define-record-type
(import (srfi :9 records)) (define-record-type <tree> (make-tree type height-m weight-kg carbon-kg) tree? (type tree-type) (height-m tree-height) (weight-kg tree-weight) (carbon-kg tree-carbon)) (define birch-young (make-tree "birch" 13 90 45)) ;; 10 year, 10cm diameter, (define birch-old (make-tree "birch" 30 5301 2650)) ;; 50 year, 50cm (define birch-weights (map tree-weight (list birch-young birch-old))) (list birch-young birch-old birch-weights)
'(#<<tree> type: "birch" height-m: 13 weight-kg: 90 carbon-kg: 45> #<<tree> type: "birch" height-m: 30 weight-kg: 5301 carbon-kg: 2650> (90 5301))
Carbon content in birch trees is about 46% to 50.6% of the mass. See forestry commission technical paper 1993.
Height from Waldwissen, weight from BaumUndErde.
Create your own modules with define-module
To provide your own module, create a file named by the module name.
For (import (example trees)) the file must be example/trees.scm. Use
define-module and #:export what gets imported:
(define-module (example trees) #:export (birch-young make-tree tree? tree-carbon)) (import (srfi :9 records)) ;; imports after module (define-record-type <tree> ;; reduced (make-tree carbon-kg) tree? (carbon-kg tree-carbon)) (define birch-young (make-tree 45)) ;; 10 year, 10cm diameter,
To use that module, add your root folder to the search path. Then just import it. To ensure that the file is run that way, use shell-indirection:
#!/usr/bin/env bash exec -a "${0}" guile \ -L "$(dirname "${0}")" -x .w $@ ;; !# Guile execution (import (example trees)) birch-young
$1 = #<<tree> carbon-kg: 45>
Make executable with chmod +x the-file.w, run with ./the-file.w
Handle errors with-exception-handler
;; unhandled exception stops execution (define (add-5 input) (+ 5 input)) ;; illegal for text (map add-5 '("five" 6 "seven")) ;; check inputs (define (add-5-if input) (if (number? input) (+ 5 input) #f)) (map add-5-if '("five" 6 "seven"))
ice-9/boot-9.scm:1685:16: In procedure raise-exception: In procedure +: Wrong type argument in position 1: "five" Entering a new prompt. Type `,bt' for a backtrace or `,q' to continue.
;; handle exceptions (define (add-5-handler input) (with-exception-handler (λ (e) (format #t "must be number, is ~S.\n" input) #f) (λ () (+ 5 input)) #:unwind? #t)) ;; #t: continue #f: stop (map add-5-handler '("five" 6 "seven"))
ice-9/boot-9.scm:1685:16: In procedure raise-exception: Syntax error: unknown location: unexpected syntax in form () Entering a new prompt. Type `,bt' for a backtrace or `,q' to continue.
In Guile Scheme checking inputs is often cheaper than exception handling.
Test your code with srfi 64
Is your code correct?
(import (srfi :64 testsuite)) (define (tree-carbon weight-kg) (* 0.5 weight-kg)) (define (run-tests) (test-begin "test-tree-carbon") (test-equal 45.0 (tree-carbon 90)) (test-approximate 45.0 (+ 40 (random 10.0)) 5) ;; expected error size (test-assert (equal? 45.0 (tree-carbon 90))) (test-error (throw 'wrong-value)) (test-end "test-tree-carbon")) (run-tests)
%%%% Starting test test-tree-carbon (Writing full log to "test-tree-carbon.log") # of expected passes 4
You can use this anywhere.
For details, see srfi 64.
Define derived logic structures with define-syntax-rule
In usual logic application in procedures, arguments are
evaluated to their return value first.
Procedures evaluate from inside to outside:
(import (ice-9 pretty-print)) (define (hello-printer . args) (pretty-print "Hello") (for-each pretty-print args)) (hello-printer 1 (pretty-print "second") 3 4) ;; prints "second" "Hello" 1 3 4
"second" "Hello" 1 #<unspecified> 3 4
But for example cond only evaluates the required branches. It is not
a procedure, but a syntax-rule.
Syntax-rules evaluate from outside to inside:
(import (ice-9 pretty-print)) (define-syntax-rule (early-printer args ...) (begin (pretty-print "Hello") (for-each pretty-print (list args ...)))) (early-printer 1 (pretty-print "second") 3 4) ;; prints "Hello" "second" 1 3 4
"Hello" "second" 1 #<unspecified> 3 4
Arguments of define-syntax-rule are only evaluated when they are
passed into a regular procedure or returned. By calling other
syntax-rules in syntax-rules, evaluation can be delayed further.
define-syntax-rule can reorder arguments and pass them to other syntax-rules
and to procedures. It cannot ask for argument
values, because it does not evaluate names as values. It operates on
names and structure.
Instead of (define (name . args) ...), it uses a pattern:
(define-syntax-rule (name args ...) ...)
The ellipsis ... marks args as standing for zero or more names. It
must be used with the ellipsis.
The body of define-syntax-rule must only have one element. The logic
begin wraps its own body to count as only one element. It returns
the value of the last element in its body.
Get and resolve names used in code with quote, eval, and module-ref
(list (quote alice)
(quote bob)
(quote carol)
(quote dave))
;; => (alice bob carol dave)
(define alice "the first")
(eval 'alice (current-module))
;; => "the first"
(module-ref (current-module) 'alice)
;; => "the first"
;; module-ref is less powerful than eval. And safer.
(define code
(quote
(list 1 2 3)))
code
;; => (list 1 2 3)
;; uses parentheses form
(eval code (current-module))
;; => (1 2 3)
'(1 2 3)
;; (1 2 3)
(list 1 2 3)
;; (1 2 3)
(equal? '(1 2 3)
(list 1 2 3))
The form '(1 2 3) is a shorthand to create an immutable
(literal) list that is equal? to list 1 2 3.
But some operations like list-set! the-list index new-value from srfi :1 do not work on immutable lists.
(define mutable-list (list 1 2 3)) (list-set! mutable-list 1 'a) ;; zero-indexed mutable-list (define immutable-list '(1 2 3)) immutable-list (list-set! immutable-list 1 'a) ;; error!
ice-9/boot-9.scm:1685:16: In procedure raise-exception:
In procedure set-car!: Wrong type argument in position 1 (expecting mutable pair): (2 3)
Entering a new prompt. Type `,bt' for a backtrace or `,q' to continue.
Build value-lists with quasiquote and unquote
(define (tree-manual type height weight carbon-content) (list (cons 'type type) (cons 'height height ) (cons 'weight weight) (cons 'carbon-content carbon-content))) (tree-manual "birch" 13 90 45) (define (tree-quasiquote type height weight carbon-content) (quasiquote ((type . (unquote type)) (height . (unquote height)) (weight . (unquote weight)) (carbon-content . (unquote carbon-content))))) (tree-quasiquote "birch" 13 90 45) (define (tree-shorthand type height weight carbon-content) `((type . ,type ) ;; ` is short for quasiquoted list (height . ,height) ;; , is short for unquote (weight . ,weight) (carbon-content . ,carbon-content))) (tree-shorthand "birch" 13 90 45)
These three methods are almost equivalent, except that quasiquoting can create an immutable list, but this is not guaranteed.
(define three 3) (define mutable-list (list 1 2 3)) (list-set! mutable-list 1 'a) ;; zero-indexed mutable-list (define immutable-list `(1 2 3)) (list-set! immutable-list 1 'a) ;; error! immutable-list (define mutable-quasiquoted `(1 2 ,three)) (list-set! mutable-quasiquoted 1 'a) ;; no error yet! mutable-quasiquoted
ice-9/boot-9.scm:1685:16: In procedure raise-exception:
In procedure set-car!: Wrong type argument in position 1 (expecting mutable pair): (2 3)
Entering a new prompt. Type `,bt' for a backtrace or `,q' to continue.
Mutating quasiquoted lists may throw an error in the future. From the standard:
A quasiquote expression may return either newly allocated, mutable objects or literal structure for any structure that is constructed at run time …
Merge lists with append or unquote-splicing
(import (ice-9 pretty-print)) (define birch-carbon/kg '(5000 5301 5500)) (define oak-carbon/kg '(7000 7700 8000)) ;; append merges lists (append birch-carbon/kg oak-carbon/kg) ;; unquote-splicing splices a list into quasiquote (`) (pretty-print `((unquote-splicing birch-carbon/kg) (unquote-splicing oak-carbon/kg))) ;; with shorthand ,@ (pretty-print `(,@birch-carbon/kg ,@oak-carbon/kg))
(5000 5301 5500 7000 7700 8000) (5000 5301 5500 7000 7700 8000)
Unquote splicing can also insert the result of logic:
`(,@(map 1- '(1 2 3)) ,@(map 1+ (reverse '(0 1 2))) (unquote-splicing (list 0)))
(0 1 2 3 2 1 0)
Document procedures with docstrings
(define (documented-proc arg) "Proc is documented" #f) ;; doc must not be last element (procedure-documentation documented-proc) ;; variables have no docstrings but ;; properties can be set manually. (define variable #f) (set-object-property! variable 'documentation "Variable is documented") (object-property variable 'documentation)
You can get the documentation with help or ,d on the REPL:
,d documented-proc => Proc is documented ,d variable => Variable is documented
For generating documentation from comments, there’s guild doc-snarf.
;; Proc docs can be snarfed (define (snarfed-proc arg) #f) ;; Variable docs can be snarfed (define snarfed-variable #f)
If this is saved as hello.scm, get the docs via
guild doc-snarf --texinfo hello.scm
Read the docs
Now you understand the heart of code. With this as the core there is one more step, the lifeblood of programming: learning more. Sources:
- the Guile Reference manual
- the Guile Library
- Scheme Requests for Implementation (SRFI): tagged libraries
- The Scheme standards (RnRS), specifically r7rs-small (pdf)
- a list of tools and libraries
- Rosetta Code with solutions to many algorithm problems
Info manuals can often be read online, but the info commandline
application and info in Emacs (C-h i) are far more efficient and
provide full-text search. You can use it to read the Guile reference
manual and some libraries. Get one by installing texinfo or Emacs.
In interactive guile (the REPL), you can check documentation:
(help string-append)
`string-append' is a procedure in the (guile) module.
- Scheme Procedure: string-append . args
Return a newly allocated string whose characters form the
concatenation of the given strings, ARGS.
,help
Help Commands [abbrev]: ...
Create a manual as package documentation with texinfo
Create a doc/ folder and add a hello.texi file.
An example file can look like the following:
@documentencoding UTF-8 @settitle Hello World @c This is a comment; The Top node is the first page @node Top @c Show the title and clickable Chapter-names as menu @top @menu * First Steps:: * API Reference:: @end menu @contents @node First Steps @chapter First Steps @itemize @item Download from ... @item Install: @code{make}. @end itemize Example: @lisp (+ 1 2) @result{} 3 @end lisp @node API Reference @chapter API Reference @section Procedures @subsection hello Print Hello @example hello @end example
Add a Makefile in the doc/ folder:
all: hello.info hello.epub hello_html/index.html hello.info: hello.texi makeinfo hello.texi hello.epub: hello.texi makeinfo --epub hello.texi hello_html/index.html: hello.texi makeinfo --html hello.texi
Run make:
make
Read the docs with calibre or the browser or plain info:
calibre hello.epub & \ firefox hello_html/index.html & \ info -f ./hello.info
The HTML output is plain. You can adapt it with CSS by adding
--css-include=FILENAME or --css-ref=URL.
Alternately you can write an Org Mode document and evaluate
(require 'ox-texinfo) to activate exporting to texinfo.
Track changes with a version tracking system like Mercurial or Git
For convenience, first initialize a version tracking repository, for example Mercurial or Git.
# either Mercurial hg init hello # or Git git init hello # enter the repository folder cd hello-scm/
Now you can add new files with
# in Mercurial hg add FILE # in Git git add FILE
And take a snapshot of changes with
# in Mercurial hg commit -m "a change description" # in Git git commit -a -m "a change description"
It is good practice to always use a version tracking system.
For additional information and how to publish your code if you want to, see the Mercurial Guide or the Git Tutorial.
Package with autoconf and automake
Create a configure.ac file with name, contact info and version.
dnl configure.ac dnl Name, Version, and contact information. AC_INIT([hello], [0.0.1], [myName@example.com]) # Find a supported Guile version and set it as @GUILE@ GUILE_PKG([3.0]) GUILE_PROGS GUILE_SITE_DIR AC_PREFIX_PROGRAM([guile]) AM_INIT_AUTOMAKE([gnu]) AC_CONFIG_FILES([Makefile]) AC_OUTPUT
Add a Makefile.am with build rules. Only the start needs to be edited:
bin_SCRIPTS = hello # program name SUFFIXES = .w .scm .sh SCHEME = hello.scm # source files hello: $(SCHEME) echo "#!/usr/bin/env bash" > "$@" && \ echo 'exec -a "$$0" guile' \ '-L "$$(dirname "$$(realpath "$$0")")"' \ '-L "$$(dirname "$$(realpath "$$0")")/../share/guile/site/3.0/"' \ '-s "$$0" "$$@"' \ >> "$@" && echo ";; exec done: !#" >> "$@" && \ cat "$<" >> "$@" && chmod +x "$@" TEXINFO_TEX = doc/hello.texi # else it needs texinfo.texi info_TEXINFOS = doc/hello.texi # add library files, prefix nobase_ preserves directories nobase_site_DATA =
The rest of the Makefile.am can be copied verbatim:
## Makefile.am technical details # where to install guile modules to import. See # https://www.gnu.org/software/automake/manual/html_node/Alternative.html sitedir = $(datarootdir)/guile/site/$(GUILE_EFFECTIVE_VERSION) GOBJECTS = $(nobase_site_DATA:%.w=%.go) nobase_go_DATA = $(GOBJECTS) godir=$(libdir)/guile/$(GUILE_EFFECTIVE_VERSION)/site-ccachep # Make sure that the mtime of installed compiled files # is greater than that of installed source files. See: # http://lists.gnu.org/archive/html/guile-devel/2010-07/msg00125.html # The missing underscore before DATA is intentional. guile_install_go_files = install-nobase_goDATA $(guile_install_go_files): install-nobase_siteDATA EXTRA_DIST = $(SCHEME) $(info_TEXINFOS) $(nobase_site_DATA) CLEANFILES = $(GOBJECTS) $(wildcard *~) DISTCLEANFILES = $(bin_SCRIPTS) $(nobase_site_DATA) # precompile all source files .scm.go: $(GUILE_TOOLS) compile $(GUILE_WARNINGS) \ -o "$@" "$<"
## Makefile.am help .PHONY: help help: ## Show this help message. @echo 'Usage:' @echo ':make [target] ...' \ | sed "s/\(target\)/\\x1b[36m\1\\x1b[m/" \ | column -c2 -t -s : @echo @echo 'Custom targets:' @echo -e "$$(grep -hE '^\S+:.*##' $(MAKEFILE_LIST) \ | sed -e \ 's/:.*##\s*/:/' -e \ 's/^\(.\+\):\(.*\)/:\\x1b[36m\1\\x1b[m:\2/' \ | column -c2 -t -s :)" @echo @echo '(see ./configure --help for setup options)'
This assumes that the folder hello uses a Version tracking system.
## Makefile.am basic additional files .SECONDARY: ChangeLog AUTHORS ChangeLog: ## create the ChangeLog from the history echo "For user-visible changes, see the NEWS file" > "$@" echo >> "$@" if test -d ".git"; \ then cd "$(dirname "$(realpath .git)")" \ && git log --date-order --date=short \ | sed -e '/^commit.*$/d' \ | awk '/^Author/ {sub(/\\$/,""); getline t; print $0 t; next}; 1' \ | sed -e 's/^Author: //g' \ | sed -e \ 's/\(.*\)>Date: \([0-9]*-[0-9]*-[0-9]*\)/\2 \1>/g' \ | sed -e 's/^\(.*\) \(\)\t\(.*\)/\3 \1 \2/g' \ >> "$@"; cd -; fi if test -d ".hg"; \ then hg -R "$(dirname "$(realpath .hg)")" \ log --style changelog \ >> "$@"; fi AUTHORS: ## create the AUTHORS file from the history if test -d ".git"; \ then cd "$(dirname "$(realpath .git)")" \ && git log --format='%aN' \ | sort -u >> "$@"; cd -; fi if test -d ".hg"; \ then hg -R "$(dirname "$(realpath .hg)")" \ --config extensions.churn= \ churn -t "{author}" >> "$@"; fi
Now create a README and a NEWS file:
#+title: Hello A simple example project. * Requirements - Guile version 3.0.10 or later. * Build the project #+begin_src bash ,# Build the project autoreconf -i && ./configure && make ,# Create a distribution tarball autoreconf -i && ./configure && make dist #+end_src * License GPLv3 or later.
hello 0.0.1 - initialized the project
And for the sake of this example, a simple hello.scm file:
(display "Hello World!\n")
Init a project with hall
To simplify the setup, start it by getting the tool guile-hall (named Hall) as described in the manual under Distributing Guile Code. Then create a new project:
hall init hello -a "My Name" \ -e "myName@example.com" \ --execute cd hello && hall build --execute
Add –license to change the license; GPLv3 or later is the default.
Hall creates a configure.ac file with name, contact information and
version, and a Makefile.am with build rules. It also automaticallyp
adds TEXINFO-rules for the folder doc/.
Open Makefile.am and add .w to SUFFIXES.
Then add the rule
.scm.go: $(AM_V_GEN)$(top_builddir)/pre-inst-env \ $(GUILE_TOOLS) compile \ $(GUILE_TARGET) $(GUILE_WARNINGS) \ -o "$@" "$<"
Deploy a project to users
Enable people to access your project as a webserver behind nginx, as clientside browser-app, or as Linux package (Guix tarball).
Browser: as webserver. On the web no one knows you’re a Scheme.
Guile provides a webserver module. A minimal webserver:
(import (web server) (web request) (web response) (web uri)) (define (handler request body) (define path (uri-path (request-uri request))) (values (build-response #:headers `((content-type . (text/plain))) #:code 404) (string-append "404 not found: " path))) (define v4 #t) ;; choose either IPv4 or IPv6; to suport both, run twice. ;; (run-server handler 'http ;; (if v4 '(#:port 8081) ;; '(#:family AF_INET6 #:port 8081)))
An nginx SSL Terminator (/etc/nginx/sites-enabled/default):
server {
server_name domain.example.com;
location / {
proxy_pass http://localhost:8081;
}
}
Set up SSL support with certbot (this edits the config file).
Browser again: clientside wasm. To run clientside, you can package your project with Hoot: build an interface and compile to wasm:
(use-modules (hoot ffi)) ;; guile-specific import (define-foreign document-body "document" "body" -> (ref null extern)) (define-foreign make-text-node "document" "createTextNode" (ref string) -> (ref null extern)) (define-foreign append-child! "element" "appendChild" (ref null extern) (ref null extern) -> (ref null extern)) (append-child! (document-body) ;; Your logic (make-text-node "Hello, world!"))
Transpile with guild compile-wasm. If you run Guix:
guix shell guile-hoot guile-next -- \
guild compile-wasm -o hoot.wasm hoot.scm
Get reflection tools from Guile Hoot (licensed Apache 2.0) with Guix:
guix shell guile-hoot guile-next -- bash -c \ 'cp $GUIX_ENVIRONMENT/share/guile-hoot/*/reflect*/{*.js,*.wasm} ./'
window.addEventListener("load", () => Scheme.load_main("./hoot.wasm", { user_imports: { document: { body() { return document.body; }, createTextNode: Document.prototype .createTextNode.bind(document) }, element: { appendChild(parent, child) { return parent.appendChild(child);}}}}));
Include reflect.js and hoot.js from a HTML page:
<html><head><title>Hello Hoot</title> <script type="text/javascript" src="reflect.js"></script> <script type="text/javascript" src="hoot.js"></script> </head><body><h1>Hoot Test</h1></body></html>
For local testing, hoot provides a minimal webserver:
guix shell guile-hoot guile-next -- \ guile -c '((@ (hoot web-server) serve))'
Linux: Guix tarball. The package is the tarball. — Ludovic
Guix can assemble a tarball of all dependencies. If you already have
an autoconf project, this just requires a guix.scm file:
(import (gnu packages web) (gnu packages bash) (gnu packages guile) (gnu packages guile-xyz) (gnu packages pkg-config) (guix packages) (guix gexp) (guix build-system gnu) (prefix (guix licenses) license:)) (define-public guile-doctests (package (name "guile-doctests") (version "0.0.1") (source (local-file "." "" #:recursive? #t)) (build-system gnu-build-system) (propagated-inputs `(("guile" ,guile-3.0) ("pkg-config" ,pkg-config) ("bash" ,bash))) (home-page "https://hg.sr.ht/~arnebab/guile-doctests") (synopsis "Tests in procedure definitions") (description "Guile module to keep tests directly in your procedure definition.") (license license:lgpl3+))) guile-doctests
First test building guix build -f guix.scm, then test running with
guix shell -f guix.scm and once both work, create your package
with:
guix pack -e '(load "guix.scm")' \ -RR -S /bin=bin -S /share=share
Copy the generated tarball. In can be executed with:
mkdir hello && cd hello && tar xf TARBALL_FILE && \ bin/doctest
Since this tarball generation is a bit finicky, there is a guile-doctests package with a working example setup.
Once you have guix pack working, you can also create dockerfiles
and other packages to deploy into different publishing infrastructure.
To be continued: Scheme is in constant development and deploying Guile programs is getting easier. Lilypond solved Windows.
Also see the Map of R7RS and the Scheme primer to keep learning.
You are ready.
Go and build a project you care about.
