These are English summaries for the collection of best practices and requirements from the German federal agency of security in information technology (BSI): IT-Grundschutz, specifically the Kompendium 2023.

PDF (drucken)

There are older official documents in English, but they don't map exactly to the newest German ones. Closest is the Compendium_2022.pdf.¹

Summary:

Always expect requirements of Information Security Management Systems (ISMS).
Most relevant are BSI GS CON.8 and APP3.1. Depending on the project, there can be more. Must be part of the tender.

This article Guile Scheme for practical examples. First it shows the requirements, then concrete measures in the following style:

LABEL: Title

Requirements

Measure

For some requirements, a solution with GNU Artanis is included. Many thanks to Nala Ginrut for those solutions!

This is a Work in Progress (WIP). The progress markers mean: RESEARCH (need so search for a good solution), IMPLEMENT (solution known, need to write example code), WRITE (tools exist, need to write it down). The current status is shown in Still to be done.

I only discuss CON (Concepts) and APP (Applications). There are others (e.g. for OPS), but I’m a software developer and these two are what I can judge.

BSI GS block CON.8

CON.8.A2: Selection of a Process Model

Choose a model how to work, for example scrum.
Security requirements have to be integrated into that model.
You MUST follow that model.

Clarify the model in the tender, if possible. Describe in which step security requirements are checked.

CON.8.A3: Selection of a Development Environment

Choose a development environment based on selection criteria.

Document the decisions from the other sections.
Use linters defined by language for code quality. Defined libraries in guix.scm
Define which browsers and OS'es and DBs to support.
To have a consistent environment between tooling,

Don't have passwords or variables in the git or Mercurial repository that hint on the DEV, TEST, PROD environment! Define them in a separate repository if needed.

RESEARCH Create linters for Guile

Do the compiler messages suffice?

CON.8.A5: Secure System Design

validate all inputs
… on the server
default settings must provide secure operation
errors or crashes must not expose information that should be protected
software must run with least possible privileges
data that should be protected must be encrypted during transmission (⇒ https) and storage.
authenticate users securely
authentication passwords must be stored with a secure hashing scheme
log security relevant events
do not ship code/config with comments to the customer that could contain secrets.

Document the system design.

You MUST validate that security requirements are fulfilled.

Use https by default.
keycloak (or similar external service) protects passwords.
log as usual, do not activate debug log level by default.
ship bytecode/binaries/jars, not source code.
use safe defaults
- e.g. only bind to 127.0.0.1:8080, not 0.0.0.0 — enable remote access only via SSL terminator

Use single-sign-on / OAUTH / JWT

Use either guile-oauth or guile-jwt while a system like keycloak handles usernames and passwords.

WRITE Use nginx as SSL terminator

RESEARCH Ship only bytecode with Guile

To ensure that, you need an autotools setup to compile the files locally and then create a local runner that adjusts the load path.

CON.8.A6: Use of External Libraries from Trusted Sources

Use libraries from trustworthy sources. Check their integrity.

Check hashes or signatures of libraries. This happens by default when you get dependencies via guix shell in a guix.scm.

CON.8.A7: Conducting Software Tests During Development

Use tests during development and check for coding errors continuously.

test the requirements
test failure states
test all APIs we document
check edge cases of input values (i.e. check for division by zero)
don't hack on production systems!

Build your package with Continuous Integration (CI) for centralized tests.
Have Unit Tests, Integration Tests, code reviews.
- Add simple unit test defintion like guile-doctests. Use SRFI-64 for larger testsuites.
- Review changes in merge requests to catch problems that can’t be caught in automated tests. For example in Forgejo (or Github) or Heptapod pull/merge requests.
- Define and document checklists for regular manual checks of areas that are relevant to the security requirements.
Don't hack on production.

CON.8.A8: Provision of Patches, Updates, and Changes

You MUST guarantee that security critical patches and updates are provided quickly; also when libraries have security updates. Provide checksums or signatures for release files.

Automate creating releases. Maybe get make distcheck working.
At the very least integrate something like sha256sum "${file}" > "${file}".sha256
Setup your package as channel to ensure all devs have the same packages via guix shell. You can use an inferior channel to pin packages to specific commits.
Automate updating libraries. Maybe adapt guix refresh for your dependency definition in guix.scm.
Create a CycloneDX SBOM, then setup OWASP Dependency-Track or Mend Renovate.

IMPLEMENT Create SBOM from Guix

Adjust guix graph: add --type=sbom

CON.8.A10: Source Code Version Management

Use a version tracking system. Create backups of it.

Version tracking with Git or Mercurial.
Have tags and release branches as defined for the project in CON.8.A2: Selection of a Process Model.
Have off-site backups of the source repository.

CON.8.A20: Checking External Components

check libraries. Either of:
- use established checks, or
- check for vulnerabilities ourselves
Check all external components with checksums or certificates (signatures).
Avoid old versions of libraries.
Prove sufficient checking.

Check hashes of libraries. Happens automatically when using guix shell; see CON.8.A6: Use of External Libraries from Trusted Sources.
Maybe use Renovate in ci/cd.

BSI GS block APP.3

APP.3.1.A1: Clients must authenticate

auth-retries must be limited

When using keycloak and oauth/jwt, configure keycloak for limited retries

Enable Brute Force Detection for Max Login Failures, locking the account for at least a few minutes.

Maybe also see the option http-max-queued-requests in Configuring Keycloak for production.

IMPLEMENT create helpers for authorized handler definition

;; default handler definition
define-authorized method : handler request body
  ;; ...
  values …
;; unauthorized
define-unauthorized method : handler request body
  ;; ...
  values …

APP.3.1.A4: Uploads must be limited as much as possible

If Uploads they are allowed:

limit to permitted clients
use restrictive access rights
ensure that files are only saved in allowed places

RESEARCH define an upload helper with configurable upload limits

always require authorization for uploads
have configurable upload locations

Artanis: configurable upload control Artanis

configurable using the artanis.conf template
For details see (upload …) definition in the code

APP.3.1.A7: Prevent unauthorized automated use.

Allow intended automated use like RSS feeds.

Ensure that any other use requires a manual login.

IMPLEMENT make authorized access the default

Use explizit unauthorized handler from APP.3.1.A1: Clients must authenticate. Make unauthorized less convenient than authorized to avoid nudging people to unsafe patterns.

RESEARCH provide rate limits configuration that rate limits by default

(to be written)

APP.3.1.A14: Protect confidential data

MUST use serverside crypto to prevent unauthorized access.
MUST use salted hash for passwords.
MUST prevent forbidden access to source files.

use trustworthy server-side salted hash method for passwords
Javascript files are sources: minimize which Javascript files are accessible without login
- in addition to CON.8.A5: Secure System Design: not having sources in production
login forms should import only the Javascript they really need

RESEARCH Use salted hash for password login

(to be written)

Alternatively avoid handling passwords and use oauth or jwt for authorization

See CON.8.A5: Secure System Design.

RESEARCH Provide static files in authorized and un-authorized flavor

Artanis: integrate oauth or jwt or use the #:auth handler Artanis

For oauth or jwt, see CON.8.A5: Secure System Design. For the auth-handler see the Authentication Section of the Artanis manual.

Still to be done

RESEARCH	IMPLEMENT	WRITE
Create linters for	Create SBOM from Gu	Use nginx as SSL te
Ship only bytecode	create helpers for
define an upload he	make authorized acc
provide rate limits
Use salted hash for
Provide static file

Footnotes:

Why would you follow these rules? Firstoff: if you want a government contract in Germany, you likely have to. Also they are pretty well-written: most of these are just common sense when you want to create reliable software. So much that if someone does not want to follow them, you can assume that using their software might put you at risk. These rules need to be enforced, because they can conflict with budget-pressure.
